Grinding and polishing series
FRT-3800 stone edge polishing&grinding machine
The machine adopt high precision castings have been assembled,walking the two-speed motor,pull the head can set bottom plate internal grinding,curves,the head can rotating 360°,flat head can be simple lines,produce products with good brightness,high efficiency.simple operation.etc.
| 型号 | TYPE | Unit | FRT-3800 | FRT-3800A |
| 磨轮直径 | Diameter of grinding wheel | mm | ￠150 | |
| 最大加工长度 | Max,processing length | mm | 3000 | 3500 |
| 最大加工宽度 | Max,processing width | mm | 600 | |
| 最大加工厚度 | Max,processing thickness | mm | 150 | |
| 主电机功率 | Main motor power | kw | 5.5 | 7.5 |
| 总功率 | Gross power | kw | 8.05 | 12.05 |
| 耗水量 | Water consumption | m3/h | 3 | |
| 外形尺寸（长x宽x高） | Overall dimension(LxWxH) | mm | 4400x2300x1600 | 4900x2300x1600 |
| 总重量 | The total weight | kg | 900 | 1000 |
